4| Monitoring and Di
agnostics
4.1 View on Home Network
Introduction
The IGD data model on the Thomson Gateway contains the object
“InternetGatewayDevice.LANDevice.1.Hosts.”.
This hosts table provides a list of all devices that are connected via the local network. For each device, the list
contains information on:
 IP address
 Address source
 Remaining lease time
 MAC address
 Host name
 Interface type
 Active status
Message flow
Following illustration shows the expected message flow to obtain the hosts table:
Example: parameter values
For example, following parameter values can be used:
 Obtaining information on the hosts table: to retrieve the hosts table, the GetParameterValues RPC
(message 1 in preceding illustration) contains following ParameterNames argument:
For example, the GetParameterValuesResponse (message 2 in preceding illustration) contains following
name-value pairs in its ParameterList argument:
ACSCPE
Transaction session
1) GetParameterValues
2) GetParameterValuesResponse
...
...
Obtain the Hosts table
Entry Value
1 InternetGatewayDevice.LANDevice.1.Hosts.
Name Value
InternetGatewayDevice.LANDevice.1.Hosts.HostNumberOfEntries 1
InternetGatewayDevice.LANDevice.1.Hosts.Host.1.IPAddress 192.168.1.64
InternetGatewayDevice.LANDevice.1.Hosts.Host.1.AddressSource DHCP
InternetGatewayDevice.LANDevice.1.Hosts.Host.1.LeaseTimeRemaining 86315
