4| Monitoring and Diagnostics
 Obtaining the test results: to retrieve the results of the test, the GetParameterValues RPC (message 9 in
preceding illustration) contains following ParameterNames argument:
For example, the GetParameterValuesResponse (message 10 in preceding illustration) contains following
name-value pairs in its ParameterList argument:
InternetGatewayDevice.IPPingDiagnostics.DSCP 0
InternetGatewayDevice.IPPingDiagnostics.DiagnosticsState Requested
Entry Value
1 InternetGatewayDevice.IPPingDiagnostics.
Name Value
InternetGatewayDevice.IPPingDiagnostics.DiagnosticsState Complete
InternetGatewayDevice.IPPingDiagnostics.SuccessCount 4
InternetGatewayDevice.IPPingDiagnostics.FailureCount 0
InternetGatewayDevice.IPPingDiagnostics.AverageResponseTime 1 (milliseconds)
InternetGatewayDevice.IPPingDiagnostics.MinimumResponseTime 1 (milliseconds)
InternetGatewayDevice.IPPingDiagnostics.MaximumResponseTime 1 (milliseconds)
Name Value
