4| Monitoring and Di
agnostics
Message flow: passive notification
Following illustration shows a possible message flow in case of passive notification:
Message flow: active notification
Following illustration shows a possible message flow in case of active notification:
ACSCPE
Transaction session
1) GetParameterAttributes
2) GetParameterAttributesResponse
...
...
4) SetParameterAttributes
5) SetParameterAttributesResponse
8) Parameter change event
6) 200 OK (Empty)
3) Verify event subscriptions,
decide to reconfigure
7) Close connection
...
9) Inform (Event 2 Periodic,
4 Value Change)
10) InformResponse
...
ACSCPE
Transaction session
1) GetParameterAttributes
2) GetParameterAttributesResponse
...
...
4) SetParameterAttributes
5) SetParameterAttributesResponse
8) Parameter change event
6) 200 OK (Empty)
3) Verify event subscriptions,
decide to reconfigure
7) Close connection
9) Inform (Event 4 Value Change)
10) InformResponse
...
