THOMSON TR-069 - Page 69

E-DOC-CTC-20071119-0003 v1.0
63
5| WAN Connections
 Configuring the PPPoA connection: the SetParameterValues RPC (message 10 in preceding illustration)
contains following name-value pairs in its ParameterList argument:
WAN IP connection with static IP address
A WAN IP connection with a static IP address can be created and configured as follows:
 Creating an IP connection: the AddObject RPC (message 7 in preceding illustration) contains for the
ObjectName argument the value
“InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.WANIPConnection.”.
The AddObjectResponse (message 9 in preceding illustration) contains for the InstanceNumber
argument for example value “1“.
 Configuring the IP connection with a static IP address: the SetParameterValues RPC (message 10 in
preceding illustration) contains following name-value pairs in its ParameterList argument:
Name Value
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANPPPConnection.1.NATEnabled
1
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANPPPConnection.1.Username
<username>
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANPPPConnection.1.Password
<password>
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANPPPConnection.1.Name
Internet
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANPPPConnection.1.Enable
1
The parameter Name is mandatory. This means that the parameter must be set before the
WANPPPConnection object is internally created.
Name Value
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANIPConnection.1.AddressingType
Static
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANIPConnection.1.ExternalIPAddress
<ipaddress>
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANIPConnection.1.SubnetMask
<mask>
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANIPConnection.1.Name
Video
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANIPConnection.1.Enable
1
The parameter Name is mandatory. This means that the parameter must be set before the
WANIPConnection object is internally created.
