THOMSON TR-069 - Page 84

E-DOC-CTC-20071119-0003 v1.0
78
6| Service Provisionin
g
 Configuring the serving pool: the SetParameterValues RPC (message 4 in preceding illustration) contains
following name-value pairs in its ParameterList argument:
 Creating a DHCP option: the AddObject RPC (message 7 in preceding illustration) contains for the
ObjectName argument the value
“InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.DHCPConditionalServingPool.1.
DHCPOption.”.
The AddObjectResponse (message 9 in preceding illustration) contains for the InstanceNumber
argument for example value “1”.
 Configuring the DHCP option: the SetParameterValues RPC (message 10 in preceding illustration)
contains following name-value pairs in its ParameterList argument:
Name Value
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.Chaddr
00:0f:1f:83:d7:5b
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.MinAddress
192.168.1.70
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.MaxAddress
192.168.1.80
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.SubnetMask
255.255.255.0
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.IPRouters
192.168.1.254
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.DHCPLeaseTime
86400
Name Value
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.DHCPOption.1.Tag
4
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement
.DHCPConditionalServingPool.1.DHCPOption.1.Value
“MTIzNDU2Nzg=”
The parameters Tag and Value are mandatory. This means that these parameters must be set
before the DHCPOption object is internally created.
