E-DOC-CTC-20071119-0003 v1.0
80
6| Service Provisionin
g
 Creating a classification table entry: the AddObject RPC (message 4 in preceding illustration) contains for
the ObjectName argument the value “InternetGatewayDevice.QueueManagement.Classification.”.
The AddObjectResponse (message 6 in preceding illustration) contains for the InstanceNumber
argument for example value “24”.
 Configuring the classification table entry: the SetParameterValues RPC (message 7 in preceding
illustration) contains following name-value pairs in its ParameterList argument:
 Creating a policer table entry: the AddObject RPC (message 10 in preceding illustration) contains for the
ObjectName argument the value “InternetGatewayDevice.QueueManagement.Policer.”.
The AddObjectResponse (message 12 in preceding illustration) contains for the InstanceNumber
argument for example value “1”.
 Configuring the policer table entry: the SetParameterValues RPC (message 13 in preceding illustration)
contains following name-value pairs in its ParameterList argument:
InternetGatewayDevice.QueueManagement.Queue.6.DropAlgorithm BLUE
InternetGatewayDevice.QueueManagement.Queue.6.SchedulerAlgorith
m
WFQ
InternetGatewayDevice.QueueManagement.Queue.6.QueueEnable 1
Name Value
InternetGatewayDevice.QueueManagement.Classification.24.Protocol 6
InternetGatewayDevice.QueueManagement.Classification.24.DSCPMark -1
InternetGatewayDevice.QueueManagement.Classification.24.ForwardingPolicy 0
InternetGatewayDevice.QueueManagement.Classification.24.ClassQueue 6
InternetGatewayDevice.QueueManagement.Classification.24.ClassPolicer -1
InternetGatewayDevice.QueueManagement.Classification.24.ClassificationEnable 1
Name Value
InternetGatewayDevice.QueueManagement.Policer.1.PolicerEnable 1
Name Value
