6| Service Provisioning
 Configuring a rule: the SetParameterValues RPC (message 10 in preceding illustration) contains
following name-value pairs in its ParameterList argument:
 Assigning a host to an application: the SetParameterValues RPC (message 13 in preceding illustration)
contains following name-value pairs in its ParameterList argument:
Name Value
InternetGatewayDevice.Services.X_000E50_NATApplicationList.
Application.130.Rule.1.ExternalPort
<ExternalPort>
InternetGatewayDevice.Services.X_000E50_NATApplicationList.
Application.130.Rule.1.ExternalPortRangeEnd
<ExternalPortRangeEnd>
InternetGatewayDevice.Services.X_000E50_NATApplicationList.
Application.130.Rule.1.InternalPort
<InternalPort>
InternetGatewayDevice.Services.X_000E50_NATApplicationList.
Application.130.Rule.1.Protocol
TCP or UDP
The parameters ExternalPort and ExternalPortRangeEnd are mandatory. This means that the
parameter must be set before the Rule object is internally created.
Name Value
InternetGatewayDevice.Services.X_000E50_NATApplicationList.
Application.130.HostIPAddress
<ipaddress>
To obtain the IP addresses of the local network devices, see “4.1 View on Home Network” on
page 48.
