1 General Information
DC31008
2
Getting Started
2.1
Unpacking
Inspect the packaging for damage.
If the shipping container seems to be damaged, keep it until you have inspected the
contents and you have inspected the DC3100 mechanically and electrically.
Verify that you have received the following items:
1. 1 DC3100 (main unit and LED head)
2. 1 Power cord, connector according to ordering country
3. 1 Power supply 12V / 3.75A
4. 1 USB cable
5. 1 Operation manual
6. 1 Applications and driver CD
2.2
Preparation
1.Connect LED head cable with socket labeled "LED" at the back of the main
control unit, see figure 1
2.Connect power supply cable with main control unit, use only the power supply
supplied with your DC3100 unit
3.Plug in power supply
Figure 1 Connecting the LED Head
ATTENTION
Prior to switching on your DC3100 please check if the line voltage
corresponds to the input voltage range of the power supply!
Turn the unit on by pressing the power switch on the rear side of the unit.
