7 Appendix
DC310042
7.3.3.3
LED @ 470nm
The DC3100-470 contains the blue LED LZ1-00B205 from LedEngin. The LED
emits a wavelength at 470nm and an optical power of up to 60lm.
The 10dB cut-off frequency of the DC3100-470 is 80MHz. The maximum current is
1000mA.
Figure 39 Phase Difference of DC3100-470
7.3.3.4
LED @ 630nm
The DC3100-630 contains the red LED LZ1-00R105 from LedEngin. The LED
emits a wavelength at 630nm and an optical power of up to 100lm.
The 10dB cut-off frequency of the DC3100-630 is 70MHz. The maximum current is
1000mA.
