7 Appendix
DC3100 39
7.3
Technical Data
7.3.1
Common Data
Line Voltage (Ext. Power Supply)
100 ... 240VAC (-10%, +10%)
Line Frequency (Ext. Power Supply)
50 ... 60Hz
Power Consumption (max)
20VA
Supply mains over Voltage
Category II (Cat II)
Input Voltage (DC3100 chassis)
12VDC
Operating Temperature
1)
0 ... +40 °C
Storage Temperature
-40 ... +70 °C
Relative Humidity
Max. 80% up to 31 °C
decreasing to 50% at 40 °C
Pollution Degree (indoor use only)
2
Operation Altitude
< 3000 m
Warm-up Time for rated Accuracy
10 min
Weight
< 1 kg
Dimensions (W x H x D) without
operating elements
160 x 80 x 150 mm³
Dimensions (W x H x D) with
operating elements
160 x 80 x 168 mm³
1)
non condensing
7.3.2
Technical Data
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity)
LED Current Range
0 ... 1000mA
Modulation Frequency Range
(Internal Modulation Mode only)
10 ... 100MHz
Modulation
(Internal Modulation Mode only)
Sine Wave
Modulation Depth
1)
(Internal Modulation Mode only)
0 ... 100%
Trigger Output
(Internal Modulation Mode only)
Sine Wave
Modulation Frequency Range
(External Control Mode only)
0 ...100kHz
(Sine Wave)
Modulation
(External Control Mode only)
Arbitrary
Trigger Input
(External Control Mode only)
max. 10V
1V corresponds to 100mA
DC3100-365
Nominal Wavelength
365nm
Maximum Current
700mA
Cut-off Frequency
90MHz
DC3100-405
Nominal Wavelength
405nm
Maximum Current
1000mA
Cut-off Frequency
95MHz
