THORLABS DC4100 User Manual

Page 21
20442_D02
DC4100 6 Appendix
6 Appendix
6.1 Technical Data
Item#
DC4100
LED Control
LED Current Range (for each Channel)
0 ... 1000mA
LED Current Resolution
1mA
LED Current Accuracy
±10mA
Compliance Voltage (for each Channel)
5V
Modulation
Modulation Frequency Range (External Control Mode only)
0 ...100kHz (Sine Wave)
Modulation (External Control Mode only)
arbitrary
Trigger Input (External Control Mode only)
max. 10V
1V corresponds to 100mA
Power Supply
Line Voltage (Ext. Power Supply)
100 ... 240VAC (-10%, +10%)
Line Frequency (Ext. Power Supply)
50 ... 60Hz
Power Consumption (max)
45VA
Supply mains over Voltage
Category II (Cat II)
Input Voltage (DC4100 chassis)
12VDC
General
Operating Temperature Range
1
)
0 to +40 °C
Storage Temperature Range
-40 to 70 °C
Relative Humidity
Max. 80% up to 31 °C
decreasing to 50% at 40 °C
Pollution Degree (indoor use only)
2
Operation Altitude
< 3000 m
Warm-up Time for Rated Accuracy
10 min
Dimensions (W x H x D) without operating elements
152 x 74 x 147 mm³
Dimensions (W x H x D) with operating elements
152 x 74 x 164 mm³
Weight
< 1 kg
1
) non-condensing
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing)
