OPERATING MANUAL TW63 TECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
3.2.3 Version with motor type IMB5/V1
1 Length of intermediate flange for motor in line with:
BV6
530-06 / Sheet 1: 0 mm
BV6530-06 / Sheet 6: 64 mm
Fig. 3.2.3
1
09-2012
