OPERATING MANUAL TW63 TECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
3.2.4 Version with emergency brake, NBS
1 With Warner brake
SZ1
700/1700 Nm
2 With Mayr brake
RSO800/2200 Nm
Fig. 3.2.4
1
2
09-2012
