OPERATING MANUAL TW63 TRANSPORT AND STORAGE
ThyssenKrupp Aufzugswerke GmbH
In the case of vertical transport with non-ThyssenKrupp motors, remove
the handwinding wheel and screw in an M12 eyebolt.
Use suitable lifting gear to lift slowly without jerking.
Once transport has been completed, the handwinding wheel must be
rem
ounted.
Rope attachment: In the case of a machine without m
achine base frame,
attach the transport rope to the transport hanger.
Pay attention to the picture symbols on the packaging or elsewhere.
This way up
Fragile goods
Protect
against
water
Protect
against heat
Hand hooks
prohibited
Attach here
Dimensions and weight
The weight data is specified on the packaging on a label below the transport
hangers.
Please refer to the delivery note for the dimensions.
Rough specifications, see chapter 2.3 'Technical data'.
Fig. 4.8 Fig. 4.9
