SIF5600 - Manual - 03 - 2008
5 I N S T A L L AT I O N
5. PACKAGING
Packaging consists of a polystyrene foam container; guaranteeing adequate protection for transport
and storage under normal environmental conditions.
It is recommended that the container not be disposed of into the environment, but kept in case the
relay should be moved at some later time.
5.2 PROJECTING MOUNTING
The SIF5600 relay is fixed onto the panel by means of screws, according to the drawings reported
below.
CB MODE
RESET
Esc
CLOSE CBOPEN CB
OFF
DISPLAY MODE
TOGLIERE TENSIONE
PRIMA DI APRIRE
F 6542 31
653 421
B
14
8765432
17 181615
1E87654
12 131110
CORTOCIRCUITARE
I SECONDARI DEI TA
PRIMA DI SCOLLEGARE
IL CONNETTORE
8 9765
321C
2 43
A
15120
230
240
=
135
=
100
152
24
Ø4.5
220
80.7
UAUX
SIF5600#3D2
50-51-50N-51N
85...275Vac / 75...300Vdc
ON
50N - 51N
50 - 51
CB OPEN
CB CLOSED
RS232
1
