69
69
SIF5600 - Manual - 03 - 2008
8.3 APPENDIX A3 - SETTING SHEET
Description Default Unit Value Range
Set
Base
Inp value
300 300 1 ... 99 step = 1
100 ... 990 step = 10
1000 ... 10000 step = 100
Inp unit 0 0 A
IEnp value
100 100 1 ... 99 step = 1
100 ... 990 step = 10
1000 ... 10000 step = 100
IEnp unit 0 0 A
Reading 1 1 Relative | Direct
Relays
K1
None None Self test | PW break
Blin1 | CB fail | PW shorted | Start I> | Start I>> |
Start IE> | Start IE>> | Trip I> | Trip I>> | Trip IE> | Trip IE>> | Open 52 |
Close 52 | Self test 52
K1 mode 0 0 DeEn-NoLatch | DeEn-Latch | En-NoLatch | En-Latch
tTR1
200 ms 200 10 ... 990 step = 10
1.00 ... 1.00 step = 0.01
K2
None None Self test | PW break
Blin1 | CB fail | PW shorted | Start I> | Start I>> |
Start IE> | Start IE>> | Trip I> | Trip I>> | Trip IE> | Trip IE>> | Open 52 |
Close 52 | Self test 52
K2 mode 0 0 DeEn-NoLatch | DeEn-Latch | En-NoLatch | En-Latch
tTR2
200 ms 200 10 ... 990 step = 10
1.00 ... 1.00 step = 0.01
K3
None None Self test | PW break
Blin1 | CB fail | PW shorted | Start I> | Start I>> |
Start IE> | Start IE>> | Trip I> | Trip I>> | Trip IE> | Trip IE>> | Open 52 |
Close 52 | Self test 52
K3 mode 0 0 DeEn-NoLatch | DeEn-Latch | En-NoLatch | En-Latch
tTR3
200 ms 200 10 ... 990 step = 10
1.00 ... 1.00 step = 0.01
K4
None None Self test | PW break
Blin1 | CB fail | PW shorted | Start I> | Start I>> |
Start IE> | Start IE>> | Trip I> | Trip I>> | Trip IE> | Trip IE>> | Open 52 |
Close 52 | Self test 52
K4 mode 0 0 DeEn-NoLatch | DeEn-Latch | En-NoLatch | En-Latch
tTR4
200 ms 200 10 ... 990 step = 10
1.00 ... 1.00 step = 0.01
50 - 51
I curve 0 0 Independent | Curve A | Curve
B | Curve C
I> indep
1.00 In 1.00 0.100 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
t> indep
400 ms 400 50 ... 990 step = 10
1.00 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 180 step = 1
I> dep
1.00 In 1.00 0.100 ... 0.999 step = 0.001
1.00 ... 2.50 step = 0.01
t> dep
1.00 ms 1.00 100 ... 990 step = 10
1.00 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
I>> indep
7.00 In 7.00 0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 20.0 step = 0.1
t>> indep
30 ms 30 30 ... 990 step = 10
1.00 ... 10.00 step = 0.01
Blin I>> 0 0 Off | On
