Phase overcurrent 50/51 - Very inverse time curve (IEC 60255-3/BS142 type B)
1.1
21 3 4 5 6 7 8 9 10 20
I /I>
dep
0.01
0.1
1
10
100
1000
10000
t [s]
t>
dep
= 10.0 s
t>
dep
= 60.0 s
t>
dep
= 30.0 s
t>
dep
= 5.00 s
t>
dep
= 1.00 s
t>
dep
= 0.50 s
t>
dep
= 0.30 s
t>
dep
= 0.10 s
K = 3 for 2.00 fw release
K = 13.5 for 2.10 and following fw releases
t =
t>
dep
·
[(I/I>
dep
) -1]
K
Note: match of operating and setting time takes place when:
I/I>
dep
= 4 for 2.00 fw release (SIF5600-Manual-10-2006” reference document)
I/I>
dep
= 14.5 for 2.10 and following fw releases
