Thytronic SIF5600 - 50 N - 51 N; 50 N - 51 N Settings; 52; 52 Settings

70
70
SIF5600 - Manual - 03 - 2008
Description Default Unit Value Range
Blout I>> 0 0 Off | On
50N - 51N
IE curve 0 0 Independent | Curve A | Curve
B | Curve C
IE> indep 0.030 In 0.030 0.002 ... 0.500 step = 0.001
tE> indep
1.00 ms 1.00 50 ... 990 step = 10
1.00 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 180 step = 1
IE> dep 0.030 In 0.030 0.002 ... 0.050 step = 0.001
tE> dep
1.00 ms 1.00 100 ... 990 step = 10
1.00 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
IE>> indep 0.050 In 0.050 0.002 ... 0.500 step = 0.001
tE>> indep
40 ms 40 30 ... 990 step = 10
1.00 ... 10.00 step = 0.01
Blin IE>> 0 0 Off | On
Blout IE>> 0 0 Off | On
52
52 local 1 1 Off | On
52 remote 0 0 Off | On
52 check 1 1 Off | On
Block
tF enable 1 1 Off | On
tF 0.25 s 0.25 0.00 ... 10.00 step = 0.01
t
B enable 1 1 Off | On
t
B 0.30 s 0.30 0.10 ... 10.00 step = 0.01
Pulse
Blin1 0 0 Off | 30 s | 10 s | 1 s | 100 ms | 50 ms
Pulse
Blout 0 0 Off | 30 s | 10 s | 1 s | 100 ms | 50 ms
Store
Time
Read time
Year 0 2000 ... 2099 step = 1
Month 0 1 ... 12 step = 1
Day 0 1 ... 31 step = 1
Hour 0 h 0 0 ... 23 step = 1
Minute 0 m 0 0 ... 59 step = 1
Second 0 s 0 0 ... 59 step = 1
Millisecond 0 ms 0 0 ... 999 step = 1
Set time
Set year 2000 2000 ... 2099 step = 1
Set month 1 1 ... 12 step = 1
Set day 1 1 ... 31 step = 1
Set hour 0 h 0 0 ... 23 step = 1
Set minute 0 m 0 0 ... 59 step = 1
Set second 0 s 0 0 ... 59 step = 1
Set millisecond 0 ms 0 0 ... 999 step = 1
Mod
Bus slave
Address 1 1 1 ... 247 step = 1
Baud rate 0 0 9600 | 4800 | 2400 | 1200
Parity 0 0 No | Even | Odd
Stop bit 0 0 1 | 2
Enable TX delay 2 ms 2 0 ... 50 step = 1
Start TX delay 1 ms 1 0 ... 10 step = 1
