Installation and Operational Instructions for
ROBA-stop
®
-Z Type 892.101.0
Size 125 (E073 01 046 000 4 EN)
18/05/2022 TK/HW/SU Chr. Mayr GmbH + Co. KG
Eichenstraße 1, D-87665 Mauerstetten, Germany
Phone: +49 8341 804-0, Fax: +49 8341 804-421
Page 7 of 16 www.mayr.com, E-Mail: public.mayr@mayr.de
Parts List (Only use mayr

original parts)
Item
Name
Pcs.
1
Hub
1
1.1
O-ring D60 x 3
2
1.2
Set screw M6 x 10
1
2
Brake body
1
2.1
Magnetic coil
1
3
Cap screw M8 x 85
3
4
Washer D16 / 8.4 x 1.6
3
5
Rotor 1
1
6
Rotor 2
1
7
Distance bolt
3
8
Thrust spring D15.5 / 2.8 x 39.5
4
9
Cable 2 x AWG18
1
10
Reference gauge
2
11
Release monitoring (page 12)
1
11.1
Microswitch
1
11.2
Hexagon head screw M5 x 20
1
11.3
Hexagon nut M5
1
11.4
Spring washer A5
1
11.5
Cap screw M4 x 8
2
12
1)
Hub
1
13
Elastomeric element
1
14
Armature disk
1
15
Brake plate
1
16
2)
Headless screw M8 x 30
2
17
2)
Plastic tube D10 / 8 x 14
2
18
3)
Hand release
1
18.1
Switch bracket A
1
18.2
Switch bracket B
2
18.3
Cap screw M8 x 14
4
18.4
Hand release rod
1
18.5
Hexagon nut M16
1
18.6
Headless screw M8 x 30
2
18.7
Flat headed screw M8 x 10
2
18.8
Thrust spring holder
1
18.9
Cap screw M6 x 25
1
18.10
Washer A6.4
1
18.11
Thrust spring D15.5 / 2.5 x 28
1
19
Noise damping
4
20
Grounding strand
1
21
Cap screw M4 x 8
2
22
Contact washer M4
2
23
4)
Hexagon nut M8
1
24
Type tag
1
We reserve the right to make dimensional and constructional alterations!
1)
On article number 8253118, the hub is not included in the standard scope of delivery.
2)
Items 16 and 17 are included loose in delivery and are not shown in the Figure.
3)
On article number 8292346, the hand release is not included in the standard scope of delivery.
4)
Plastic nut, serves only as transportation lock.
