TKE TW45 - Mass moment of inertia; Weight

36
Technology
Mechanical data
TK Elevator
BA, TW45 | 6231003860 | 03/2023
Ratio / η
g
η
g'
η
n
η
an
η
an
'
40:3 0.86 0.88 0.88 0.90 0.91 0.66 0.66
32:3 0.87 0.89 0.89 0.91 0.92 0.67 0.67
Tab.11 ATR_1_21_0051_0
4.1.10 Mass moment of inertia
Machine
location
J
rot
Machine room
ASY TW45C winch
1)
(kgm
2
) 0.0045 x
Motor 5.2 kW (kgm
2
) 0.018 x
Motor 7.0 kW (kgm
2
) 0.024
Handwinding wheel D270 (kgm
2
) 0.01 x
ASY complete machine (kgm
2
) - 0.0325
Tab.12 ATR_1_21_0049_0
The following values for the machine apply to the ISIS1 versions depending on
the motor construction size:
▪ E 5.5 J
rot
= 0.028 kgm²
▪ E 7.5 J
rot
= 0.036 kgm²
▪ E 11.0 J
rot
= 0.040 kgm²
The mass moment of inertia for versions of the machine not listed in the table
is to be determined according to the details of the individual components.
4.1.11 Weight
Machine location Weight [kg] Machine room
ASY TW45C winch
1)
120 x
ASY TW45C winch
2)
160 x x
Motor 5.2 kW 50 x x x
Motor 7.0 kW 60
Traction sheave D590 60
Traction sheave D520 55 x x
Traction sheave D440 45 x
ASY complete machine [kg] - 225 275 285
Tab.13 ATR_1_21_0007_0
1)
Version without emergency brake.
2)
Version with emergency brake, NBS
The following values for the machine apply to the ISIS1 versions depending on
the motor construction size:
▪ E 5.5 m = 227 kg
▪ E 7.5 m = 240 kg
▪ E 11.0 m = 245 kg
The overall mass for versions of the machine not listed in the table is to be de-
termined according to the weight data of the individual components.
