6. Secure the machine against slipping and falling over.
7. In the case of machines without a machine base frame, attach a transport
rope to the transport eyebolts.
Fig.24 ATR_2_21_0046_0
8. Use the thread fitted below the vertical version of the motor for transport
hooks.
NOTICE!
Do not damage the handwinding wheel. Ropes or chains must not
make contact with the handwinding wheel during transport.
9. Use the transport hanger with the horizontal version.
5.5 Checking the delivery
WARNING
Severe transport damage to the product.
Can lead to a malfunction of the product and thus to death or serious injury.
Before commissioning, ensure that there is no severe damage to the
product.
