TKE TW45 - Motor versions

32
Technology
Mechanical data
TK Elevator
BA, TW45 | 6231003860 | 03/2023
r v
n
n1 DT i vn1 Q´max F´max x
825 1300 45
1330 590 41:2
675
1300
50
750 45
1160 440 40:3
900
1500
50
1000 45
Tab.7 ATR_1_21_0048_0
r - Rope suspension
v
n
fpm (m/s) rated speed
n1 (rpm) Motor speed
DT in (mm) Diameter of traction sheave
i - Gear ratio
Q´max lbs (kg) Rated load (maximum)
F´max lbs (kg) Mass of car (maximum at Q´max)
x (%) Counterweight compensation
Applications in the ISIS1
r v
n
n1 DT i Q´max F´max x
2:1
100
(0.508)
970
10.5
(267)
40:3
3000
(1361)
3500
(1588)
45
150
(0.762)
1455
10.5
(267)
40:3
200
(1,016)
1555
10.5
(267)
32:3
Tab.8 ATR_1_21_0050_0
r - Rope suspension
v
n
fpm (m/s) rated speed
n1 (rpm) Motor speed
DT in (mm) Diameter of traction sheave
i - Gear ratio
Q´max lbs (kg) Rated load (maximum)
F´max lbs (kg) Mass of car (maximum at Q´max)
x (%) Counterweight compensation
All specified performance data in
Chap.4.1.5P.30 apply to the following
application conditions:
▪ Operating data max. 180 c/h at 50% duty cycle
▪ Ambient temperature + 5°C to + 40°C
For types of performance not shown in the chart or deviating installation data,
there is the possibility to use a calculation program (e.g. TK Liftdesigner) to
check the operational safety of the machine.
The machines are conceived for a service life of at least 15 years and/or
20,000 hours of operation.
4.1.6 Motor versions
Standard versions of motors
Designation Unit Technical data
Manufacturer EME (CEG)
Type MT132STD MT132STD
