TKE TW45 - Page 33

Technology
Mechanical data 33
TK Elevator
BA, TW45 | 6231003860 | 03/2023
Designation Unit
Technical data
20197S 20193S
Motor version
C5.2 400 C7.0 400
TKAW designation
Voltage/frequency [V/Hz] 340/42
S5 operating data 180 c/h / 50% DC
Speed range [rpm] 1000-1249 1250-1800 1000-1249 1250-1800
Power output [kW] 4.2-5.2 5.2 5.6-7.0 7.0
Torque [Nm] 40 40-28 54 54-37
Rated current [A] 12.5 16.5
Permitted starting
torque
[Nm] 70 70-63 88 88-79
Permitted starting cur-
rent
[A] 20 25
Effective voltage [V] 340 340
cos ϕ 0.87 0.88
Efficiency 0.82 0.82
Design IMB5/V1
Type of protection IP55
Ventilation Internal ventilator
Handwinding wheel
1)
[mm] D270 (plastic)
kproj. [mm] 485
Weight [kg] 50 60
Actual-value sensor WDG100-38-1024/4096 TTL
Tab.9 ATR_1_21_0034_0
Motors in voltage interchangeable version with CSA for ISIS1
Designation Unit Technical data
Manufacturer EMOD
Type 132S/4 132M/4 132M/4a
Motor version
TKAW designation
E5.5 230/460 E7.5 230/460 E11.0 230/460
S5 operating data 180 c/h / 50% DC
Rated speed [rpm] 970 1460 1555 970 1460 1555 970 1460 1555
Nominal frequency [Hz] 34.0 50.4 53.7 34.0 50.7 53.7 34.0 50.7 54.0
Rated voltage
1)
[V]
156//
312
230//460
156//
312
230//460
156//
312
230//460
Rated power [kW] 3.7 5.5 5.5 5.0 7.5 7.5 7.4 11 11
Rated torque [Nm] 36.4 36.0 33.8 49.2 49.1 46.1 72.8 71.9 67.5
Rated current [A] 21.0//10.5
20.4//
10.2
28.0//14.0
27.2//
13.6
41.0//20.5
39.0//
19.5
max. starting torque [Nm] 45 100 140
Max. starting current [A] 42//21 56//28 86//43
