6.3 Mounting the frame with rope pulley
NOTICE
One-sided load on component and or drive set up on a slant!
Failure of the drive involving damage.
The drive must be horizontal.
Use a spirit level to check; add support if necessary.
Secure the drive on the machine base frame against shifting with ad-
justing screws or stops.
Arrange the suspension ropes symmetrically on the suspension plate,
traction sheave and rope pulleys.
