Transportation and storage
Packaging 47
TK Elevator
BA, TW45 | 6231003860 | 03/2023
5 Transportation and storage
5.1 Packaging
NOTICE
Rust on components of the drive!
Damage and possibly loss of function of the product.
Check the "anti-corrosion foil" for damage.
In the case of larger traction sheaves, the gear housing is bolted onto wooden
blocks.
Fig.22 ATR_2_21_0044_0
The gear housing is bolted directly onto the pallet (special pallet 1200x800)
Fig.23 ATR_2_21_0045_0
Further packaging depends on the order and is country-specific (air/sea/land
freight).
Refer to the delivery note for the dimensions and weight.
Observe the symbols attached to the packaging or in visible locations.
Dispose of used packing material in an environmentally responsible man-
ner.
Specific transport equipment and shipping braces remain with the customer.
