Input 2 channels, –50/–36/–10/+4 dB* (Selectable with the DIP switch), 4.7 kΩ,
electronically-balanced, 3-pin removable terminal block
Phantom power supply (+15 V, can be set with the DIP switch)
Ground lift switch (can be set with the DIP switch)
A/D Converter 20 bits
Sampling Frequency 48 kHz
Frequency Response 20 – 20,000 Hz, ±1 dB (+4 dB* input)
Dynamic Range Over 85 dB (IHF-A weighted) (+4 dB* input)
Total Harmonic Distortion Under 0.2% (+4 dB* input)
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 125 g
20.5. D-922E Microphone/Line Input Module (Optional)
Input 4 stereo inputs (Selection of 1 stereo or mixing or all 4 stereo inputs)
–10 dB*, 10 kΩ, RCA pin jack
A/D Converter 24 bits
Sampling Frequency 48 kHz
Frequency Response 20 – 20,000 Hz, ±1 dB (+4 dB* input)
Dynamic Range Over 100dB (IHF-A weighted)
Total Harmonic Distortion Under 0.05%
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 145 g
20.6. D-936R Stereo Input Module (Optional)
• Accessories
3-pin removable terminal plug (preinstalled on the unit) ........... 2
20.7. D-923AE Digital Input Module (Optional)
20.8. D-937SP Digital Input Module (Optional)
Input 2 channels, 2.0 – 7.0 V (p-p), 110 Ω, equivalent to XLR-3-31
Applicable Format AES/EBU (2 channel multiplexed)
Sampling Frequency 32 – 48 kHz
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 130 g
Input Stereo 1 channel (Selectable one of 4 inputs)
0.5 V (p-p), 75 Ω, Coaxial RCA pin jack x 2
Square optical connector x 2
Applicable Format S/PDIF (2 channel multiplexed)
Sampling Frequency 32 – 48 kHz
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 130 g
* 0 dB = 0.775 V
Note: The design and specifications are subject to change without notice for improvement.
