92
Output 4 channels, +4 dB*, adaptable load of over 600 Ω, electronically-balanced,
3-pin removable terminal block
D/A Converter 24 bits
Sampling Frequency 48 kHz
Frequency Response 20 – 20,000 Hz, ±1 dB
Dynamic Range Over 100dB (IHF-A weighted)
Total Harmonic Distortion Under 0.05%
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 140 g
20.10. D-971E Line Output Module (Optional)
Output 4 channels (2 outputs for each channel), –10 dB*,
adaptable load of over 600 Ω, RCA pin jack
D/A Converter 24 bits
Sampling Frequency 48 kHz
Frequency Response 20 – 20,000 Hz, ±1 dB
Dynamic Range Over 100dB (IHF-A weighted)
Total Harmonic Distortion Under 0.05%
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 150 g
20.11. D-971R Line Output Module (Optional)
• Accessories
3-pin removable terminal plug (preinstalled on the unit) ........... 2
* 0 dB = 0.775 V
Note: The design and specifications are subject to change without notice for improvement.
Output 4 channels, +4 dB*, adaptable load of over 600 Ω, electronically-balanced,
equivalent to XLR-3-32 type
D/A Converter 24 bits
Sampling Frequency 48 kHz
Frequency Response 20 – 20,000 Hz, ±1 dB
Dynamic Range Over 100dB (IHF-A weighted)
Total Harmonic Distortion Under 0.05%
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 165 g
20.9. D-971M Line Output Module (Optional)
20.12. D-972AE Digital Output Module (Optional)
Output 4 channels, 5.0 V (p-p), 110 Ω, equivalent to XLR-3-32
Applicable Format AES/EBU (2 channel multiplexed)
Sampling Frequency 48 kHz
Finish Panel: Pre-coated steel plate, black (30% glossy)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm
Weight 130 g
• Accessories
Ferrite clamp ............................................................................. 2
To Next Page
