Chapter 3 INSTALLATION AND SETTING PROCEDURES (HARDWARE)
To make longer cable lengths than those shown in the above table, use over 4-pair shielded CPEV cable. (For
the cable connection, see p. 3-47.)
The relationship of the CPEV cable conductor diameter to the maximum cable distance is as follows:
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
STP Category 5 92 m 68 m 54 m 44 m
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
STP Category 5 37 m 32 m 28 m 25 m
No. of extension
units
No. of extension
units
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
ø0.65 mm 152 m 113 m 89 m 73 m
ø0.9 mm 296 m 220 m 174 m 143 m
ø1.2 mm 524 m 389 m 308 m 253 m
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
ø0.65 mm 62 m 54 m 47 m 42 m
ø0.9 mm 121 m 105 m 92 m 82 m
ø1.2 mm 215 m 186 m 163 m 145 m
No. of extension
units
No. of extension
units
• WhentheVX-3000DSisoperatingonbattery
The following table shows the maximum cable distance when STP Category 5 straight cable (with RJ45
connectors) is used.
