3-51
Chapter 3 INSTALLATION AND SETTING PROCEDURES (HARDWARE)
To make longer cable lengths than those shown in the above table, use over 4-pair shielded CPEV cable. (For
the cable connection, see below.)
The relationship of the CPEV cable conductor diameter to the maximum cable distance is as follows:
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
STP Category 5 355 m 266 m 213 m 177 m
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
STP Category 5 152 m 133 m 118 m 106 m
No. of extension
units
No. of extension
units
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
ø0.65 mm 586 m 440 m 352 m 293 m
ø0.9 mm 1141 m 856 m 684 m 570 m
ø1.2 mm 1200 m 1200 m 1200 m 1010 m
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
ø0.65 mm 251 m 220 m 195 m 176 m
ø0.9 mm 489 m 428 m 380 m 342 m
ø1.2 mm 865 m 757 m 673 m 606 m
No. of extension
units
No. of extension
units
• When the VX-3000DS is operating on AC power
To make longer cable lengths than those shown in the above table, use over 4-pair shielded CPEV cable. (For
the cable connection, see below.)
The relationship of the CPEV cable conductor diameter to the maximum cable distance is as follows:
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
STP Category 5 111 m 83 m 66 m 55 m
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
STP Category 5 47 m 41 m 37 m 33 m
No. of extension
units
No. of extension
units
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
ø0.65 mm 183 m 137 m 110 m 91 m
ø0.9 mm 356 m 267 m 214 m 178 m
ø1.2 mm 631 m 473 m 378 m 315 m
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
ø0.65 mm 78 m 68 m 61 m 55 m
ø0.9 mm 152 m 133 m 118 m 107 m
ø1.2 mm 270 m 236 m 210 m 189 m
No. of extension
units
No. of extension
units
• When the VX-3000DS is operating on battery
The maximum distance of power cable between the RM-300X and the VX-3000DS is as follows.
The following table shows the maximum cable distance when STP Category 5 straight cable (with RJ45
connectors) is used.
The maximum distance of power cable between the RM-300X and the VX-3000DS is as follows.
The following table shows the maximum cable distance when STP Category 5 straight cable (with RJ45
connectors) is used.
