4-16
Chapter 4
APPENDIX
2.7. VX-300LO Line Output Module
Power Source Supplied from the VX-3000 Frame (DA CONTROL LINK)
Current Consumption*
1
Max. 2 mA (Current through DC POWER IN)
Input DA CONTROL LINK: Connector (15 pins)
Audio Output*
1
1 channel
Output signal level: 0 dB*
2
Adjustable range of the volume control knob: –∞ to 0 dB
Output method: 10 kΩ, transformer-balanced
Applicable load impedance: 2 kΩ or more
Frequency Response: 40 Hz – 20 kHz ±1 dB
Distortion: 1 % or less (0 dB*
2
output, 1 kHz)
Signal to Noise Ratio: 60 dB or more
Removable terminal block (3 pins)
Operating Temperature 0 to 40 °C (32 to 104 °F)
Operating Humidity 90% RH or less (no condensation)
Finish Surface-treated steel plate
Dimensions 76 (w) x 39 (h) x 33.2 (d) mm (2.99" x 1.54" x 1.31")
Weight 56 g (0.12 lb)
*
1
When installed in the VX-3000 Frame.
*
2
0 dB = 1 V
Note: The design and specications are subject to change without notice for improvement.
• Accessories
DA control link Cable ................................. 1
Removable terminal plug (3 pins) .............. 1
Mount base ................................................ 2
Machine screw with washer M4 x 8.............1
