TOHATSU MFS 4C Service Manual

11-17
4st 4/5/6 2011
11
1 Intake Manifold Ass'y 1
2 Intake Manifold Gasket 1
3 Bolt 2 M6 L=25mm
4-1 Carburetor Ass'y 1 4ps
4-2 Carburetor Ass'y 1 5ps
4-3 Carburetor Ass'y 1 6ps
5-1 Main Nozzle 1 5ps
5-2 Main Nozzle 1 4ps
5-3 Main Nozzle 1 6ps
6-1 Main Jet (#68) 1 5ps
6-2 Main Jet (#62) 1 4ps
6-3 Main Jet (#70) 1 6ps
7 Slow Jet (#38) 1 4/5/6ps
8 Float 1
9 Float Valve 1
10 Clip 1
11 Float Arm Pin 1
12 Float Chamber 1
13 Float Chamber O-Ring 1
14 Screw 2 M4 L=12mm
15 Drain Screw 1
16 O-Ring Drain Screw 1
17 Stop Screw 1
18 Spring Stop Screw 1
19-1 Pilot Screw 1 4ps
19-2 Pilot Screw 1 5/6ps
20 Carburetor Gasket 2
21 Insulator 1
22 Intake Silencer 1
23 Collar 6.2-9-7.4 2
24 Bolt 6-85 2 M6 L=85mm
25 Washer 2 M6
26 Fuel Pump Ass'y 1 Mark “D”
27 Check Valve (P) 1 Black
28 Check Valve (R) 1 White
29 Pump Body Gasket 1
30 Pump Diaphragm 1
31 Screw 2 M3 L=8mm
32 Screw 4 M4 L=18mm
33 O-Ring 2.62-18.72 1
34 Screw 2 M6 L=30mm
35 Choke Wire 1
36 Cable Holder 1
37 Screw 1 M5 L=10mm
38 Fuel Filter Ass'y 1
39 LowPermeationHose 1 USA
40 Fuel Hose 1 STD
41 LowPermeationHose 1 USA
42 Fuel Hose 1 STD
43 Hose 2 L=270mm
44 Clip 4
45 Mount Rubber 9-16-4.3 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
