TOHATSU MFS 4C Service Manual

11-18
2. Parts Layout
4st 4/5/6 2011
Recoil Starter P/L Fig. 5
1 Recoil Starter Ass'y 1
2 Starter Case 1
3Starter Spring Set 1
4 Starter Spring 1
5 Reel 1
6 Return Spring 2
7 Ratchet 2
8 Friction Spring 1
9 Bolt Starter Shaft 1
10 Friction Plate 1
11 Starter Rope ø4.5-1620 1
12 Starter Handle 1
13 Rope Anchor 1
14 Sealing Plate Starter 1
15 Starter Seal 1
Ref.
No.
Description Remarks
Q'ty
16 Starter Lock 1
17 Collar 4-6-21 1
18 Starter Lock Spring 1
19 Starter Lock Cam 1
20 Washer 1 M6
21 Screw 1 M6 L=16mm
22 Rod Snap 1
23 Collar 6.1-8-6.5 1
24 Starter Lock Cam Spring 1
25 Screw 1 M4 L=30mm
26 Pre Coated Bolt 3
27 Clamp 6.5-47.5P 1
28 Caution Decal (B) 1
29 Starter Lock Rod 1
30 Rod Snap 3.5-2 1
Ref.
No.
Description Remarks
Q'ty


 




























LIT
GREASE
LIT
LIT
GREASE
LIT
LIT
GREASE
LIT
TB
13421342
1342
     
TB
1741
1741
1741
1741
LIT
GREASE
LIT
TB
13421342
1342
ADH
174117411741
1741
