TomTom Bandit Reference Guide

14
2. When you see a dot and arrow to the left of the release lever the Batt-Stick can be inserted as
described above.
Charging your TomTom Bandit
You can charge your TomTom Bandit in the following two ways:
Charging the Batt-Stick using a USB socket
Important: If you remove the Batt-Stick or lens cover be extra careful not to let dirt or water enter
the TomTom Bandit or the Batt-Stick. Only remove the Batt-Stick or lens cover in clean and dry
conditions.
1. Remove the Batt-Stick from the TomTom Bandit.
2. Insert the Batt-Stick USB connector into your computer's USB socket or a standard USB
wall-charger.
Tip: While the Batt-Stick is charging, the LEDs show the charge level and one LED flashes.
3. To see the power level of the Batt-Stick, remove the USB connector from the USB charging
socket, then press the ON button.
The LEDs light up to show the power level.
4. When the Batt-Stick is charged, install the Batt-Stick into the TomTom Bandit.

TomTom Bandit Specifications

General

Photo Resolution	16 MP
Sensor	CMOS
Battery	1900 mAh
Battery Life	Up to 3 hours
GPS	Yes
Resolution	4K
Image Sensor Size	1/2.3-inch
Field of View	160°
Storage	MicroSD card (up to 128GB)
Connectivity	Wi-Fi, Bluetooth
Sensors	Accelerometer, Gyroscope
Dimensions	94 x 38 x 52 mm
Weight	190 grams
Frame Rate	30fps (4K), 60fps (1080p), 120fps (720p)
Waterproof	IPX7 (without additional housing), IP68 with optional lens cover
