Console Controls
5.1. Using the master switch
When Virtual has been selected in the Setup screen (Implement /
Master Switch), the harvester master switch on the Operation screen
turns the harvester system on. This switch does not work if Follows
device work state is selected as the master switch.
The switch also indicates the readiness of the system:
Red
Harvester controller is off and cannot be used. Select the master
switch to see possible causes of the problem. See example below.
Green
Harvester controller is on and working. Select the master switch to
turn the harvester off.
White
Harvester Controller is ready to use. Select the master switch to turn
the harvester on.
Green indicates that the system is ready.
Red indicates that the system is not
ready.
Select to return to the main
screen and complete the necessary
action.
Note: When the master switch is turned off during harvesting, the
master switch flashes yellow and a countdown is displayed. This
