Upgrading ECU Firmware
The YieldTrakk ECU firmware can be upgraded from the Factory
Setup screen, see page 53.
The firmware upgrade files must be placed in the root directory of a
USB flash drive in the following folder structure:
• (folder) Ceres / (folder) Updates.cms / (files) 538XXXYY.bin
and 538XXXYY.mop
Where X is the issue number and Y is the revision number.
1. Insert the USB drive into the console’s USB port.
2. Select the Factory Setup screen, press GO and enter the
password.
3. Select the Upgrade Software icon .
The firmware upgrade version is displayed.
4. Select the Upgrade Software icon again.
The screen displays ‘Saving Data’, then ‘Loading Software’. Do
not remove the USB until the process is complete.
Before removing the USB, always disconnect first by touching
the USB Eject icon on the base of the console . A message
will display that it is safe to remove the USB.
