Chapter 5 – Console Controls
29
• Applied rate map (dry yield): Calculated T/Ha (Bu/Ac) based
on current wet yield data with respect to the desired moisture
reference point (i.e. after it has dried).
• Applied rate map (moisture): Percentage raw moisture sensor
data.
• Applied rate map (raw yield): Reports exactly what the yield
sensor is measuring at that point in time in T/Hr. Sometimes
referred to as productivity.
• Applied rate map (cut rate): Ha/Hr (Bu/Hr) based on speed and
working width. Sometimes used as a measurement of
productivity.
Coverage shows in green.
Applied rate shows in selectable colors.
Legend displays for applied rates.
5.4.1. Editing the legends
The legends that are displayed for Applied Rate may be edited.
1. Click on the legend to display the legend color and range map.
