Topcon Europe Medical BV Instruction Manual CC-100XP/ CV-5000PC 22/42
The tests for which this inversion method is applicable:
Fixation disparity test Fixation disparity test
Phoria test Fixation disparity test
Fixation disparity test
Fixation disparity test
Figure 28, Tests that can be inverted by auxiliary lens change
8.1.3 Selecting a Red-Green test
Worth Four Dots test
Figure 29, Worth four dots test
When the above test is selected by pressing the related button, the related test will be
displayed in CC-100XP and the related Auxiliary filters will be engaged within CV-5000
optical head.
Note: More charts are available to be implemented within the Polarization chart page.
These tests are:
Maddox chart
Figure 30, Schober chart
Schober chart
Figure 31, Schober chart
For the procedure to implement the charts by replacing other standard
implemented charts, please refer to the KB-50 operation manual.
