T
opcon Europe Medical BV
Instruction Manual CC-100XP/ CV
-5000PC
23/42
9
Operation in the CONTRAST T
ab p
age.
The CONTRAST
T
ab looks like under image
Figure 32, Contrast tab page
Within the CONRAST T
ab page it is possible to
perform 2 different
contrast tests; the
Contrast Sensitivity test and the S
pat
ial Frequency Contrast Sensitivity test.
22
24
