D4008 – EN EZ 2810 Operators Manual 32
SETTING
[display]
D.A.N
NO.
OPTIONS [displayed]
BOLD=DEFAULT
DESCRIPTION
PRINT FORMAT
2304
AUTO, WTONLY,
DOWNLD, DT+TM,
ID+TM, IDWTTM,
BATCH1, PRTAC1,
PRTAC2, PRTAC3,
PRWTRC,
WTRCTM,3200-A, 3200-
B, SCLABC
Select alternate & comma (CSV) formats.
PRINT
ACCUMULATION
2305 Shows a running total of weights printed.
REMOTE
DISPLAY
2401
EZ2, EZ3MUX,
COG,NONE
Select type of remote display
REMOTE
TERMINAL
2402 ON/OFF Sends display data to serial remote terminal interface
BAR GRAPH
MODE
2411
OFF, RIGHT, LEFT,
MIDOUT, MID IN
Selects output for a bar graph display when used with an RD4000
Remote Display
WEIGHT GRAPH
2412 ON/OFF
Enables graph to be used with weight when used with a RD4000
Remote Display.
BAR WEIGHT
2413
12000 Enter the full scale gross weight for the bar graph display.
PRESET GRAPH
2414
ON/OFF
Enables graph to be used with presets when used with an RD4000
Remote Display.
TIMER GRAPH
2415 ON/OFF
Enables graph to be used with timers when used with an RD4000
Remote Display.
3001
.01,.02,.05,.1,.2,.5,1,2,5,1
0,20, 50,100
Select display count size of weigh values.
CAPACITY
3002 40,000 Enter MAXIMUM weight measurable on scale.
WM1 ADJUST 1
3003 10 thru 19 Increase this number to smoothing weighing
WM1 ADJUST 2
3004 0 thru 9 0=off. Use value less than WMA1-1 for quick response weight.
WM1 ADJUST 3
3005
4000
Enter the weight to active quick response weight
Default-10% of scale capacity
WM2 ADJUST 1
3006 30 thru 39 Increase this number to smoothing weighing
WM2 ADJUST 2
3007 10 thru 19 10=off. Use value less than WMA2-1 for quick response weight.
WM2 ADJUST 3
3008 4000
Enter the weight to active quick response weight
Default-10% of scale capacity
MOTION
3101 ON/OFF
ON = Motion arrow flashes with unstable weight. Prevents: Print,
Zero, Tare, Advance
MOTION
WEIGHT
3102 0 Enter weight used to detect motion. 0=Standard detection
PRE ALARM
METHOD
4001 WEIGHT, PERCENT Select weight or percentage method for pre-alarm
