6-27
6 SPECIAL MODE (Menu Mode)
z Input CURVE data
Operating procedure Operation Display
1 To input CURVE data, press the [F2] key. *1)
[F2]
2 Input RADIUS.
3 Press the [ENT] key.
4 Input LENGTH.
5 Press the [ENT] key.
6 Select TURN(direction of turn): RIGHT or LEFT.
7 Press the [ENT] key.
Input
RADIUS
[ENT]
Input
LENGTH
[ENT]
Select
[F1]
(LEFT)
or
[F2]
(RIGHT)
[ENT]
*1) CURVE cannot be input as the first data.
F1:LINE
F2:CURVE
F3:SPIRAL
F4:POINT
CURVE 02
R = 0.000 m
L : 0.000 m
––– ––– [CLR][ENT]
CURVE 02
R : 100.000 m
L = 0.000 m
––– ––– [CLR][ENT]
CURVE 02
TURN > RIGHT
LEFT RIGHT ––– ENTER
<SET!>
