34
MAINTENANCE AND CHECKUPS
DAILY CARE
•This instrument may be affected adversely by dust. Apply the dust cover when not using.
PLACING AN ORDER FOR CONSUMABLES
•When ordering consumable items, contact your dealer or TOPCON (see the back cover).
Specify the article name, product code and quantity.
USER MAINTENANCE ITEMS
RESTOCKING CHINREST TISSUE
When the chinrest tissue supply is depleted, pull out the chinrest tissue pins and replace tissue.
Article name Product code
Chinrest tissue 403104082
Item Inspection time Contents
Inspection Before using • Adjusting the diopter and pupillary distance
• Focus of slit image
• The base unit must move smoothly.
• The components must be fitted in place correctly.
• The chinrest unit must be fitted to the table unit correctly.
• The cables and plugs must be connected correctly.
• The objective lens, eyepiece and mirror must not be stained or
damaged.
Cleaning When the part is
stained
• Objective lens
• Eyepiece
• Mirror
• Sliding plate, rail and wheel shaft unit
• Forehead rest and chinrest unit
Adjustment As required • Slit width control knob torque
• Inclination torque of illumination unit
Supply As required • Chinrest tissue
