SPECIFICATIONS AND PERFORMANCE
SPECIFICATIONS AND PERFORMANCE
*1, A model without fixation target is also available.
• The specification and design of the product can be altered for improvements without prior notice.
Microscope unit
Type Galileo type
Magnification Drum, 5-step magnification
Magnification steps 6/10/16/25/40
Overall magnification (actual vision field)
6.37 (φ35.1mm)
9.94 (φ22.5mm)
15.87 (φ14.1mm)
25.37 (φ8.8mm)
39.62 (φ5.6mm)
Eyepiece lens
Magnification: 12.5x
Diopter adjustment range: -5D to +5D
PD adjustment range
55 to 78mm
Barrier filter
Available for use IN/OUT the sight (A model, with or without bar-
rier filter, is available. The model with barrier filter houses the
Illumination Unit with exciter filter.)
Illumination unit
Illumination field
Slit width: 0 to14mm, can be altered gradually(14mm=circle)
Slit length: 1 to14mm, can be altered gradually(14mm=circle)
Aperture diameter φ14, 10, 5, 2, 1, 0.2mm
Slit direction Vertical to horizontal, can be altered gradually
Inclination
5°, 10°, 15,° 20° from below
Available for use side swing
Filter
Blue filter, red-free filter, ND filter (13% transmission), amber fil-
ter, UV cut filter (normal use), IR cut filter (normal use), exciter fil-
ter (A model, with or without exciter filter, is available. The model
with exciter filter houses the Microscope Unit with barrier filter.)
Illumination lamp 3A 10W LED
Base unit
Forward-backward movement length 90mm
Right-left movement length 100mm
Vertical movement length 30mm
Fine adjustment in all directions length 12mm
Chinrest unit
Adjustable range of the vertical direction 80mm
Fixation target*
1
Fixation target with diopter adjustment
Light source for fixation target: LED
