Toro 03540 Reelmaster 5200-D - Brake Pedals; Throttle Control; Fuel Gauge; Key Switch

Figure 18
1. Traction speed limiter 5. Parking brake latch
2. Reel control light 6. Locking pin
3. Speedometer 7. Key switch
4. Brake pedals
Reel Control Light
T his light ( Figure 18 ) illuminates when the glo w
plugs are preheating, or blinks when there is a
control system problem or when the g round speed
during mo wing approac hes the maxim um preset
mo wing speed.
Speedometer
T he speedometer ( Figure 18 ) indicates the g round
speed at whic h mac hine is tra v eling .
Brake Pedals
T w o foot pedals ( Figure 18 ) operate indi vidual
wheel brak es for tur ning assistance , parking, and
to aid in obtaining better side-hill traction. A
loc king pin connects the pedals for parking brak e
operation and transpor t.
Parking Brake Latch
A knob on the left side of console ( Figure 18 )
actuates the parking brak e loc k. T o eng ag e the
parking brak e , connect the pedals with the loc king
pin, push do wn on both pedals , and pull the
parking brak e latc h out. T o release parking brak e ,
press both pedals until the parking brak e latc h
retracts .
Key Switch
T he k ey switc h ( Figure 18 ) has three positions:
Off , On/Preheat, and Star t.
Engine Coolant Temperature Warning
Light
T his light ( Figure 19 ) illuminates and the engine
shuts do wn when the engine coolant reac hes a
dang erously high temperature .
Figure 19
1. Lower mow/raise control
lever
6. Glow plug indicator light
2. Fuel gauge 7. Charge indicator
3. Engine coolant
temperature gauge
8. Throttle control
4. Engine oil pressure warning
light
9. Enable/disable switch
5. Engine coolant
temperature warning
light
Throttle Control
Mo v e the throttle control ( Figure 19 ) forw ard to
increase the engine speed and rearw ard to decrease
speed.
Fuel Gauge
T he fuel g aug e ( Figure 19 ) sho ws the amount of
fuel in the tank.
Lower Mow/Raise Control Lever
T his lev er ( Figure 19 ) raises and lo w ers the cutting
units and also star ts and stops the reels .
Glow Plug Indicator Light
T his light ( Figure 19 ) blinks when the glo w plugs
are preheating .
23
