Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Steeringwheel
1
Cap
1
1
Washer1
Installthesteeringwheel.
ROPSframe
1
2
Bolt,1/2inch
6
MounttheROPS(RolloverProtection
System)
3
Electrolyte
A/R
Activateandchargethebattery.
4
Nopartsrequired
–
Checktheengineoil,transaxle/hydraulic
uid,andbrakeuidlevels
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Readbeforeoperatingthevehicle
PartsManual1
Usetoreferencepartnumbers
OperatorTrainingMaterial
1
Viewbeforeoperatingmachine
Note:Determinetheleftandrightsideofthemachinefromthenormaloperatingposition.
1
InstalltheSteeringWheel
(TCModelsOnly)
Partsneededforthisprocedure:
1
Steeringwheel
1
Cap
1Washer
Procedure
1.Removethenutfromthesteeringshaft.Slidethe
steeringwheelandwasherontothesteeringshaft
(
Figure3).
2.Securethesteeringwheeltotheshaftwiththenut
andtightenitto20-25ft-lb(27–34N-m).
3.Installthecaponthesteeringwheel.
Figure3
1.Steeringwheel3.Cap
2.Nut4.Washer
