2.Loosenthejamnutssecuringthedifferentiallock
cabletothebracketonthetransaxle(Figure57).
Figure57
1.Differentiallockcable3.Spring
2.Transaxlebracket
4.0.01to0.06inch(0.25to
1.5mm)gap
3.Adjustthejamnutstoobtaina0.01to0.06inch
(0.25to1.5mm)gapbetweenthespringhookand
theO.D.oftheholeinthetransaxlelever.
4.Tightenthejamnutswhennished.
InspectingtheTires
ServiceInterval:Every100hours
Operatingaccidents,suchashittingcurbs,candamagea
tireorrimandalsodisruptwheelalignment,soinspect
tireconditionafteranaccident.
Checkthetirepressurefrequentlytoensureproper
ination.Ifthetiresarenotinatedtothecorrect
pressure,thetireswillwearprematurely.
Figure58isanexampleoftirewearcausedbyunder
ination.
Figure58
1.Underinatedtire
Figure59isanexampleoftirewearcausedbyover
ination.
Figure59
1.Overinatedtire
CheckingtheFrontWheel
Alignment
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
1.Makesurethetiresarefacingstraightahead.
2.Measurethecenter-to-centerdistance(ataxleheight)
atthefrontandrearofthesteeringtires(
Figure60).
Themeasurementmustbewithin0±0.12inch(0
±3mm)atthefrontofthetirethenattherearof
thetire.Rotatethetire90degreesandrecheckthe
measurement.
Important:Checkthemeasurementsat
consistentlocationsonthetire.Thevehicle
shouldbeonaatsurfacewiththetiresfacing
straightahead.
Figure60
1.Frontofvehicle3.Centertocenterdistance
2.0±0.12inch(0±3mm)
fronttorearoftire
3.Adjustthecenter-to-centerdistanceasfollows:
A.Loosenthejamnutatthecenterofthetierod
(Figure61).
48
