ElectricalSystem
Maintenance
Fuses
Thefusesforthemachine’selectricalsystemarelocated
underthecenterofthedashpanel(
Figure51and
Figure52).
Figure51
1.Fuses
Figure52
JumpStartingtheVehicle
WARNING
Jumpstartingcanbedangerous.Toavoidpersonal
injuryordamagetoelectricalcomponentsin
vehicle,observethefollowingwarnings:
•Neverjumpstartwithavoltagesourcegreater
than15voltsD.C.Thiswilldamagetheelectrical
system.
•Neverattempttojumpstartadischargedbattery
thatisfrozen.Itcouldruptureorexplodeduring
jumpstarting.
•Observeallbatterywarningswhilejumpstarting
yourvehicle.
•Besureyourvehicleisnottouchingthejump
startvehicle.
•Connectingcablestothewrongpostcould
resultinpersonalinjuryand/ordamagetothe
electricalsystem.
1.Squeezethebatterycovertoreleasethetabsfrom
batterybase.Removethebatterycoverfromthe
batterybase(Figure53).
Figure53
1.Batterycover
2.Connectajumpercablebetweenthepositivepostsof
thetwobatteries(Figure54).Thepositivepostmay
beidentiedbya+signontopofthebatterycover.
3.Connectoneendoftheotherjumpercabletothe
negativeterminalofthebatteryintheothervehicle.
ThenegativeterminalhasNEGonthebatterycover.
Donotconnecttheotherendofthejumpercableto
thenegativepostofthedischargedbattery.Connect
ittotheengineorframe.Donotconnectthejumper
cabletothefuelsystem.
