EngineMaintenance
InspectingtheCarbonCanister
AirFilter
ServiceInterval:Aftertherst50hours
Every200hours
1.Locatetheairlteronthebottomofthecarbon
canister(Figure45).
1
G016089
Figure45
1.Filteropening
2.Ensurethattheopeningonthebottomofthelter
isclearandopen.
ServicingtheAirCleaner
ServiceInterval:Every200hours—Changetheair
cleanerlter.(morefrequentlyin
dustyordirtyconditions)
Inspecttheaircleanerandhosesperiodicallytomaintain
maximumengineprotectionandtoensuremaximum
servicelife.Checktheaircleanerbodyfordamagewhich
couldpossiblycauseanairleak.Replaceadamagedair
cleanerbody.
Inspectandchangetheaircleanerlterasdescribedin
thefollowingprocedure:
1.Pullthelatchoutwardandrotatetheaircleaner
covercounterclockwise.
Figure46
1.Aircleanercover2.Filter
2.Beforeremovingthelter,uselowpressure
air(40psi,cleananddry)tohelpremovelarge
accumulationsofdebrispackedbetweentheoutside
oftheprimarylterandthecanister.
Important:Avoidusinghighpressureairwhich
couldforcedirtthroughthelterintotheintake
tract.Thiscleaningprocesspreventsdebris
frommigratingintotheintakewhentheprimary
lterisremoved.
3.Removeandreplacetheprimarylter.
Note:Cleaningoftheusedelementisnot
recommendedduetothepossibilityofdamageto
theltermedia.
4.Inspectthenewlterforshippingdamage,checking
thesealingendofthelterandthebody.
Important:Donotuseadamagedelement.
5.Insertthenewlterbyapplyingpressuretotheouter
rimoftheelementtoseatitinthecanister.
6.Cleanthedirtejectionportlocatedintheremovable
cover.Removetherubberoutletvalvefromthe
cover,cleanthecavity,andreplacetheoutletvalve.
7.Installthecoverorientingtherubberoutletvalvein
adownwardposition—betweenapproximately5:00
to7:00whenviewedfromtheend.
8.Securethecoverlatches.Resettheindicatorifitis
showingred(ifsoequipped).
ChangingtheEngineOilAnd
Filter
ServiceInterval:Aftertherst50hours
