Toro 07367 - Removing the Full Bed; Installing the Full Bed

Figure33
1.Bedsupport3.Bed
2.Cylinderbarrel
4.Whennished,removethebedsupportfromthe
cylinderandinsertitintothebracketsontheback
oftheROPSpanel.
CAUTION
Donottrytolowerbedwithbedsafetysupport
oncylinder.
RemovingtheFullBed
1.Starttheengine.Engagethehydraulicliftleverand
lowerthebeduntilthecylindersarelooseinthe
slots.Releasetheliftleverandturnofftheengine.
2.Removethelynchpinsfromtheouterendsofthe
cylinderrodclevispins(
Figure34).
Figure34
1.Bedmountingplate4.Lynchpin
2.Cylinderrodend5.Rearslots(Fullbed)
3.Clevispin6.Frontslots(2/3bed)
3.Removetheclevispinssecuringthecylinderrod
endstothebedmountingplatesbypushingthepins
towardstheinside(Figure34).
4.Removethelynchpinsandclevispinssecuringthe
pivotbracketstotheframechannels(
Figure34).
5.Liftthebedoffofthevehicle.
CAUTION
Thefullbedweighsapproximately325lb(147.5
kg),sodonottrytoinstallorremoveitby
yourself.Useanoverheadhoistorgetthehelp
oftwoorthreeotherpeople.
6.Storethecylindersinthestorageclips.Engagethe
hydraulicliftlockleveronthevehicletoprevent
accidentalextensionoftheliftcylinders.
InstallingtheFullBed
Note:Ifthebedsideswillbeinstalledontheatbed,
itiseasiertoinstallthembeforeinstallingthebedon
thevehicle.
Note:Ensurethattherearpivotplatesareboltedto
thebedframe/channelsothatlowerendanglestothe
rear(Figure35).
