Toro 07367 - Hour Meter; Fuel Gauge; Light Switch; Oil Pressure Warning Light

HourMeter
Indicatesthetotalhoursofmachineoperation.The
hourmeter(Figure10)startstofunctionwheneverthe
keyswitchisrotatedtotheOnpositionoriftheengine
isrunning.
3rdHighLockoutSwitch
Movethe3rdhighlockoutswitch(Figure10)totheslow
positionandremovethekeytopreventtheuseofthird
gearwhenintheHighrange.Theenginewillshutoff
iftheshiftleverismovedtothirdgearwheninHigh
range.Thekeyisremovableineitherposition.
LightSwitch
Pushthelightswitch(Figure10)totoggletheheadlights
onoroff.
OilPressureWarningLight
Theoilpressurewarninglightglows(Figure10)ifthe
engineoilpressuredropsbelowasafelevelwhilethe
engineisrunning.Ifthelightickersorremainson,
stopthevehicle,turnofftheengine,andchecktheoil
level.Iftheoillevelwaslow ,butaddingoildoesnot
causethelighttogooutwhentheengineisrestarted,
turntheengineoffimmediatelyandcontactyourlocal
Torodistributorforassistance.
Checktheoperationofwarninglightsasfollows:
1.Applytheparkingbrake.
2.TurntheignitionkeytotheOnposition,butdonot
starttheengine.Theoilpressurelightshouldglow
red.Ifthelightdoesnotfunction,eitherabulbis
burnedoutorthereisamalfunctioninthesystem
whichmustberepaired.
Note:Ifenginewasjustturnedoff,itmaytake1to2
minutesforthelighttocomeon.
CoolantTemperatureGaugeandLight
Registersthecoolanttemperatureintheengine.
OperatesonlywhentheignitionswitchisinOnposition
(Figure10).Theindicatorlightwillilluminateblinking
rediftheengineoverheats.
ChargeIndicator
Illuminateswhenbatteryisbeingdischarged.Iflight
illuminatesduringoperation,stopvehicle,turnoff
engineandcheckforpossiblecauses,suchasalternator
belt(Figure10).
Important:Ifalternatorbeltislooseorbroken,do
notoperatethevehicleuntiladjustmentorrepairis
complete.Failuretoobservethisprecautionmay
resultindamagetotheengine.
Checktheoperationofwarninglightsasfollows:
•Applyparkingbrake.
•TurntheignitionkeytotheOnposition,butdonot
starttheengine.Thecoolanttemperature,charge
indicator,andoilpressurelightsshouldglow .Ifany
lightdoesnotfunction,eitherabulbisburnedout
orthereisamalfunctioninthesystemwhichmust
berepaired.
FuelGauge
Thefuelgaugeshowstheamountoffuelinthetank.It
operatesonlywhenignitionswitchisintheOnposition
(
Figure10).Redindicateslowfuellevelandblinking
redindicatesnearempty.
HighFlowHydraulicsSwitch(TC
modelsonly)
Turnontheswitchtoactivatethehighowhydraulics
(Figure10).
HornButton(TCmodelsonly)
Pressingthehornbuttonactivatesthehorn(Figure10).
Tachometer
RegisterstheRPMoftheengine(Figure10&Figure11).
WhitetriangleindicatesdesiredRPMforPTOoperation
(
Figure11).
Figure11
1.RPMoftheengine2.3300RPMfor540RPM
PTOoperation
18
