Toro 07367 - Controls System Maintenance; Adjusting the Accelerator Pedal; Adjusting the Clutch Pedal

ControlsSystem
Maintenance
AdjustingtheAccelerator
Pedal
1.Positionthevehicleonalevelsurface,stopthe
engine,andengagetheparkingbrake.
2.Adjusttheballjointontheacceleratorcable
(
Figure72)toallow0.200to0.350inch(5to8.9mm)
ofclearancebetweentheacceleratorpedalarmand
thetopofthediamondtreadoorplate(Figure72),
whena20lb(9kg)forceisappliedtothecenterof
thepedal.Tightenthelocknut.
Note:Theenginemustnotberunningandthe
returnspringmustbeattached.
WARNING
Thegovernorispresetatthefactorytoa
maximumenginespeedof3650rpm.Ifthe
speedisnotcorrect,refertotheWorkman
ServiceManualorcontactyourauthorizedToro
Dealer/Distributorforassistance.
Figure72
1.Acceleratorcable2.Balljoint
Figure73
1.0.200to0.350inch(5to8.9mm)clearance
AdjustingtheClutchPedal
ServiceInterval:Every200hours
Note:Youcanadjusttheclutchpedalcableatthebell
housingorattheclutchpedalpivot.Thefronthoodcan
beremovedtoeasetheaccesstopedalpivot.
1.Loosenthejamnutssecuringtheclutchcabletothe
bracketonthebellhousing(
Figure74).
Figure74
1.Clutchcable
3.Returnspring
2.Jamnuts4.Balljoint
Note:Youmayremoveandrotatetheballjoint,if
additionaladjustmentisrequired.
2.Disconnectthereturnspringfromtheclutchlever.
3.Adjustthejamnutsorballjointuntiltheback,rear
edgeoftheclutchpedalis3.75±0.12inch(9.5±0.3
cm)fromthetopoftheoorplatediamondpattern,
whenan4lb(1.8kg)forceisappliedtothepedal
(Figure75).
53
